The Atom Series Centraliser | Wilson Geophysics

Field-proven high quality centralisation.

Increased success rate during tool recovery operations

Deployed across a wide range of tools including optical and acoustic televiewers, full-wave sonic, Nuclear Magnetic Resonance and borehole cameras operating in demanding hostile borehole environments.

Designed for applications where accurate centralization and reliable recovery are critical to data integrity and tool longevity.

— Non-Magnetic Construction Prevents interference with sensitive magnetic logging instruments.
— High Wear-Resistance Polymer Blades Engineered for extended service life in abrasive formations and deviated holes.
— Tool-Free Assembly No screwdrivers required—reduces rig-side installation time and simplifies blade replacement.
— Hinged Blade Architecture Improved flexibility and resilience compared to traditional rigid plastic centralizers, reducing the risk of hang-ups during retrieval.
— Modular Configuration Supports up to 8 blades per ring set, allowing tailored centralization for varying borehole diameters and tool requirements.

Designed &Compatible with all standard sonde and borehole sizes .

Custom sizing availble upon request.

Designed for Safer Tool Retrieval

The tape-on design allows for the centralizer to pull free from the tool with less force than the clamp-on design. Should the tool need to be pulled free, the centralizer can be dropped in the borehole without causing extra damage to the tool housing and sensors.

Standard + Custom Sizing Available

We manufacture and supply a range of blade sizes from 3 inch to 20 inch and all sizes in between.

Rings can also be suited to each tool size. Currently we supply rings for 20 mm to 90 mm sondes.

Custom sizes can be made to order for both blades and rings.

Request a Quote
